Allion leads the industry with the first PCIe® 6.0 test fixture series supporting all form factors, featuring our exclusive One-Piece Solution to streamline complex validation tasks and speed up the development process.
We Provide the Solutions You Need
Products Specs
Overview
● PCIe CEM Slot by 16 Test Fixture (APT25012)
● PCIe CEM CAL Board (APT25012-CAL)
● Allion CMTS Board (APT23011)
● SMPM by 8 Cable Module*5 (4 for Tx, 1 for Rx)
Application Area
● PCI Express Host Compliance Test for Tx/Rx (Gen1-Gen6)
● PCI Express Electrical Signal Quality Validation for Tx/Rx (Gen1-Gen6)
● Applicable for Server, IPC, Notebook, Desktop or system product which has designed PCIe CEM Slot by 16 form factor
Overview
● PCIe CEM Slot by 8 Test Fixture (APT25017)
● Allion CMTS Board (APT23011)
● SMPM by 8 Cable Module*3 (2 for Tx, 1 for Rx)
_
Application Area
● PCI Express Host Compliance Test for Tx/Rx (Gen1-Gen6)
● PCI Express Electrical Signal Quality Validation for Tx/Rx (Gen1-Gen6)
● Applicable for Server, IPC, Notebook, Desktop or system product which has designed PCIe CEM Slot by 16 form factor
Overview
● PCIe OCP Slot by 16 Test Fixture (APT25013)
● Allion CMTS Board (APT23011)
● SMPM by 8 Cable Module*5 (4 for Tx, 1 for Rx)
Application Area
● PCI Express Host Compliance Test for Tx/Rx (Gen1-Gen6)
● PCI Express Electrical Signal Quality Validation for Tx/Rx (Gen1-Gen6)
● Applicable for Server, IPC, Notebook, Desktop or system product which has designed PCIe OCP Slot by 16 form factor
Overview
● PCIe E1/E3 Slot by 8 Test Fixture (APT25015)
● Allion CMTS Board (APT23011)
● SMPM by 8 Cable Module*3 (2 for Tx, 1 for Rx)
Application Area
● PCI Express Host Compliance Test for Tx/Rx (Gen1-Gen6)
● PCI Express Electrical Signal Quality Validation for Tx/Rx (Gen1-Gen6)
● Applicable for Server, IPC, Notebook, Desktop or system product which has designed PCIe E1/E3 Slot by 8 form factor
Overview
● PCIe M.2 CLB6.0 Test Fixture (APT22105)
● PCIe M.2 Calibration board (APT22105-CAL)
● Allion CMTS Board (APT23011)
● SMPM by 8 Cable Module*2
Application Area
● PCI Express Host Compliance Test for Tx/Rx (Gen1-Gen6)
● PCI Express Electrical Signal Quality Validation for Tx/Rx (Gen1-Gen6)
● Applicable for Server, IPC, Notebook, Desktop or system product which has designed PCIe M.2 Socket
Overview
● PCIe U2/U3 Slot by 16 Test Fixture (APT25042)
● Allion CMTS Board (APT23011)
● SMPM by 8 Cable Module*3
_
Application Area
● PCI Express Host Compliance Test for Tx/Rx (Gen1-Gen6)
● PCI Express Electrical Signal Quality Validation for Tx/Rx (Gen1-Gen6)
● Applicable for Server, IPC, Notebook, Desktop or system product which has designed PCIe U2/U3 form factor
